3 Layers Co-Extrusion Rotary Die Head Film Blowing Machine

Model: ABA CO-EX

product video

3 Layers Co-Extrusion Rotary Die Head Film Blowing Machine

Suitable material:HDPE LDPE LLDPE

Film width:1200-2000mm

Flim thickness:0.03-0.20mm

Max. output:250kg/hr

Max.die size:500mm

Suitable Material:

HDPE
LDPE
LLDPE

Film Width:

1200-2000mm

Flim Thickness:

0.03-0.20mm

Max. Extrusion Output:

250kg/hr

Inquiry Now

Compare

T-Shirt Bag with Printing

Plastic Vest Bag

Supermarket Flat Bag

Shopping Bags

Flat Bag

Three layer co extrusion film blowing technology

3SJ-G series three layer co-extrusion rotary die head film blowing machine set adopts the three-layer co extrusion blown film technology, which can composite different material layers together at once, fully utilizing the advantages of each layer of material, and greatly improving the physical properties such as thickness, transparency, and tensile strength of the product.

High degree of automation

3SJ-G series three layer co-extrusion rotary die head film blowing machine set has advanced automation functions, including centralized feeding, batching, weight control, automatic thickness control, and fully automatic central winding. All integrated into the touch screen integrated control, easy to operate, one person can operate, reducing the difficulty and workload of manual operation, and improving production capacity and efficiency.

Efficient production capacity

3SJ-G series three layer co-extrusion rotary die head film blowing machine set has efficient production performance and can simultaneously process three types of raw materials to extrude three-layer films, effectively improving production efficiency and reducing production costs.

FAQ

- +

How is the after-sales service? How long does the machine warranty last?

Once you purchase our machine, we guarantee to provide comprehensive lifelong after-sales service, including repair, technical support, training, and consultation. Our after-sales team will provide you with thoughtful service and help you solve any problems or difficulties encountered in using machine company products. All machines we sell come with a 12-month warranty.

- +

What technical support does your company provide?

We provide multiple technical support channels, including phone, online chat, and expatriate personnel. You can find all the information about technical support on our website. We are committed to providing our customers with the best support services and ensuring that all questions receive timely and professional responses.

- +

How to purchase products from your company?

You can purchase our products through our company's official website or search for our authorized agents in the market. If you encounter any problems during the purchasing process, our team will be available to provide assistance and support at any time.

- +

Do you need an agent in your factory?

We need to hire agents, please feel free to inquire for more details.

- +

What is your delivery time?

Usually delivered within 30 days. But it depends on the order and machine model.

- +

How long can your machine work continuously?

Our machines can work 24 hours a day without interruption, which not only increases production but also saves energy.

Model	ABC-1300	ABC-1600	ABC-2100
Suitable material	HDPE LDPE LLDPE	HDPE LDPE LLDPE	HDPE LDPE LLDPE
Film width	800-1200mm	1000-1500mm	1200-2000mm
Flim thickness	0.028-0.20mm	0.028-0.20mm	0.03-0.20mm
Max. Extrusion output	150kg/hr	200kg/hr	250kg/hr
Screw diameter	Aφ50 Bφ55 Cφ50	Aφ55 Bφ65 Cφ55	Aφ65 Bφ75 Cφ65
Screw l/d length	32:1	32:1	32:1
Main motor	A18.5kw+B22kw+C18.5kw	A22kw+B30kw+C22kw	A30kw+B37kw+C30kw
Die size	300mm	350mm	500mm
Air blower	7.5kw	11kw	15kw
Roller width	1300mm	1600mm	2100mm
Take-up motor	1.5kw	2.2kw	2.2kw
Winding motor	1.5kw	2.2kw	2.2kw
Outline dimension(L×W×H)	9.5×4.5×7.5m	10.5×5.0×9m	11.5×5.5×10m
