FILM BLOWING MACHINE
Taiwan Type ABA Caco3 Blown Film MachineTaiwan Type ABA Caco3 Blown Film Machine

Taiwan Type ABA Caco3 Blown Film Machine



Model: SJ-ABA-800/1000

Taiwan Type ABA Caco3 Blown Film Machine



Model: SJ-ABA-800/1000
PRODUCT INFORMATION

Categories:    Film Blowing Machine

Brand:    Zhuxin

Model:     High speed SJ-ABA1000

Function:    Polyethylene film

Inverter:    Delta / Shanghai NS Brand

Main Motor:    Simens / Nanjing Weinuo Brand

Electric:    Schneider / CHINT Brand

Temperature:    Omron / Shanghai ZT Brand

Screw:     high speed type

Winding Motor:    Worm Speed Reducer (Better)

Die:    HDPE and LDPE

FOB port:    Ningbo Sea Port

Terms of Payment:    L/C,Western Union,T/T



Taiwan Type ABA Caco3 Blown Film Machine

Model :SJ-ABA

Suitable material:HDPE  LDPE LLDPE

Film width:200-1000mmm

Film thickness:HD(0.009-0.15mm);LD(0.02-0.15mm).

Max extrusion output: HD(100KG);LD(130KG).

gear case:GB180*2;HANGZHOU Xiaoshan.

Inverter:(22KW*2),made in china

Low-voltage apparatus Made in china

Voltage 380V,50HZ,3PHASE.

Extruder

Screw diameter:ø55mm*2.

Screw L/D  length:1:30

Screw material: Sacm-645/38Crmoala

Cylinder material: Sacm-645/38Crmoala

Cylinder cooling:370W(3P).

Feed device cooling:  water circulating.

Main motor:22KW *2.。Made in china

Temperature control: Average power consume:40KW.

Heating areas: 4zone*2

Drum loader: Auto Loder

Type of die

Die size: ø100mm..Taiwan style high speed die head.

Temperature control.3 zone temperature controller.

Air ring. Dual-lip air ring(Taiwan style)

Height of air ring:200mm.

Width of air ring: ø760mm.

Air blower:5.5KW,. Made in china.

Center steady stick:1P.

Wind pipe: φ70×6pcs.

Take-up unit

Electrical controller system(1:7.5)+2.2KW.Twrbine Reducer(1:7.5)+2.2kw motor.

Take-up unit: 2m

knurling roll: φ130×1100mm..Controlled by air

Pinch roller: φ165×1100mm.

Roller width:1100mm.

Effective width:1000mm.

Height adjustable:800mm.

Take-up speed: 10-100m/min.

Take-up motor:1.1KW.

Winding unit  : Auto rewinder

Type: surface friction type

Winder:1.1KW..Speed controlled by inverter.

Winding speed: 10-100m/min.

Adjustable rubber roller before winding    Effective motor and control system:1.1KW .Turbine reduce controlled by inverter

Winding roller : air shaft 2pcs

THE ELECTRICAL CONTROL AND MEASURING LENGTH DISPLAY OF THE PINCH AND WINDER SHOULD INSTALL ON THE PLACE OF WINDER
Temperature controller

Switch box &contactor

Outline dimension:7.5*3.5*7.5(M).








We are committed to providing you with professional Taiwan Type ABA Caco3 Blown Film Machine solutions! Guided by the international and domestic markets, we will continue to develop and expand the scale of the company, improve the quality of , film blowing machine, blown film machine, taiwan type blown film machine, three layer ABA blown film machine, high speed ABA blown film machine products, and establish a complete quality assurance system and production management system. We insist that the quality standard of each product must be higher than the industry level to ensure that the product reaches a unified standard and quality.
