JD-400/650/850 High Speed Food Bag Making Machine
JD-400/650/850 high speed food paper bag making machine has the advantages of fast speed, high production efficiency, and wide adjustment range. This paper bag machine completes the folding, forming, bag cutting, gluing, bottom folding, bottom pasting, and finished bag output of roll paper in one go. The entire machine is controlled by a computer central control system, displayed on a touch screen, and controlled by servo motors to control the length of paper bags. The entire process is completed by the human-machine interface PLC, which has fully automatic feeding, photoelectric correction, and tension control. It is currently the ideal equipment for producing eco-friendly paper bags such as snack bags, bread bags, vomit bags, dried fruit bags, etc. both domestically and internationally.
Inquiry Now
Compare
| Model | JD-400 | JD-650 | JD-850 |
| Paper Weight | 40-80g/m² | 40-80g/m² | 40-80g/m² |
| Bag Length | 160-420mm | 220-650mm | 220-850mm |
| Bag Width | 70-260mm | 80-300mm | 80-350mm |
| Paper Bag Insert | 20-120mm | 20-120mm | 20-120mm |
| The Width Of Paper Roll | 260-720mm | 260-840mm | 260-960mm |
| Machine Speed | 60-400pcs/min | 60-400pcs/min | 60-400pcs/min |
| Machine Power | 10kw | 10kw | 10kw |
| Machine Total Weight | 3000kg | 4200kg | 5200kg |
| Machine Dimension(LxWxH) | 2100x4500x1900m | 2100x5000x2000mm | 2100x5300x2000mm |
1. Suitable for paper weighing 30-100 grams
2. The length of the bag can be set arbitrarily within a certain range on the touch screen human-machine interface
3. PLC programmable servo control system
4. Accurate color code tracking system
5. Automatic alarm and shutdown for color code errors
6. Automatic lubrication and oil supply system
Once you purchase our machine, we guarantee to provide comprehensive lifelong after-sales service, including repair, technical support, training, and consultation. Our after-sales team will provide you with thoughtful service and help you solve any problems or difficulties encountered in using machine company products. All machines we sell come with a 12-month warranty.
We provide multiple technical support channels, including phone, online chat, and expatriate personnel. You can find all the information about technical support on our website. We are committed to providing our customers with the best support services and ensuring that all questions receive timely and professional responses.
You can purchase our products through our company's official website or search for our authorized agents in the market. If you encounter any problems during the purchasing process, our team will be available to provide assistance and support at any time.
We need to hire agents, please feel free to inquire for more details.
Usually delivered within 30 days. But it depends on the order and machine model.
Our machines can work 24 hours a day without interruption, which not only increases production but also saves energy.
